Model |
|
Diesel 3.0T |
GTFD30Y-Y |
GTFD30Y-I |
|
|
|
Power |
|
|
|
|
1 |
Engine |
Model |
|
Yanmar 4TNE98 |
Isuzu C240PKJ-30 |
2 |
Rated Power |
kw/r.p.m |
42.1/2300 |
34/2500 |
3 |
Rated Torque |
Nm/r.p.m |
193.6/1700 |
138/1800 |
4 |
Bore×Stroke |
mm |
98×110 |
86x102 |
5 |
Cylinder Amount |
|
4 |
4 |
6 |
Displacement |
L |
3.318 |
2.369 |
7 |
Gears |
|
1/1 Power Shift |
1/1 Power Shift |
8 |
Working Pressure |
Mpa |
17.5 |
17.5 |
9 |
Battery |
Voltage |
V/Ah |
12/90 |
12/90 |
|
Features |
|
|
|
|
10 |
Rated Load |
kg |
3000 |
3000 |
11 |
Lifting Height |
mm |
3000 |
3000 |
13 |
Free Lifting Height |
mm |
145 |
145 |
12 |
Load Center |
mm |
500 |
500 |
14 |
Fork Size |
Long×Wide×Thick |
mm |
1070x125x45 |
1070x125x45 |
15 |
Mast Dip Angle |
Front/Rear |
。 |
6/12 |
6/12 |
16 |
Minimum Turning Radius |
mm |
2400 |
2400 |
17 |
Minimum Stacking Right Angle Aisle Width |
mm |
4280 |
4280 |
18 |
Minimum Right Angle Aisle Width |
mm |
2120 |
2120 |
19 |
Minimum Ground Clearance |
mm |
120 |
120 |
20 |
Front Overhang |
mm |
475 |
475 |
|
Performance |
|
|
|
|
21 |
Max.Travelling Speed |
Full load |
km/h |
20 |
20 |
22 |
Max. Lifting Speed |
Full load/without loading |
mm/s |
470/520 |
470/520 |
23 |
Max. Traction |
Full load |
KW |
18 |
18 |
24 |
Max. Gradeability |
% |
20 |
20 |
25 |
Max. Fork Lifting height |
With Load Backrest |
mm |
4265 |
4265 |
|
Dimension |
|
|
26 |
Overall Length |
Without Fork |
mm |
2695 |
2695 |
27 |
Overall Width |
mm |
1230 |
1230 |
28 |
Overhead Guard Height |
mm |
2090 |
2090 |
29 |
Mast Landing Height |
mm |
2055 |
2055 |
|
Chassis |
|
|
|
|
30 |
Tire |
Front |
|
28x9-15-12PR |
28x9-15-12PR |
31 |
Rear |
|
6.50-10-10PR |
6.50-10-10PR |
32 |
Wheel Base |
mm |
1700 |
1700 |
33 |
Wheel Tread |
Front/Rear |
mm |
1000/970 |
1000/970 |
34 |
Fuel Tank Volume |
L |
70 |
70 |
|
Curb Weight |
|
|
|
|
35 |
|
No-load |
Kg |
4350 |
4350 |
