Model |
Diesel 5.0T |
Diesel 5.0T |
|
|
GTFD50Y-I |
GTFD50Y-P |
|
Power |
|
|
|
|
1 |
Engine |
Model |
|
Isuzu 6BG1 |
Perkins1104D-44 |
2 |
Rated Power |
kw/r.p.m |
83/2000 |
55.9/2200 |
3 |
Rated Torque |
Nm/r.p.m |
417/1500 |
265/1700 |
4 |
Bore×Stroke |
mm |
105×125 |
105×127 |
5 |
Cylinder Amount |
|
6 |
4 |
6 |
Displacement |
L |
6.949 |
4.4 |
7 |
Gears |
|
2/2 Power Shift |
2/1 Power Shift |
8 |
Working Pressure |
Mpa |
20 |
18.5 |
9 |
Battery |
Voltage |
V/Ah |
(12/90)x2 |
(12/90)x2 |
|
Features |
|
|
|
|
10 |
Rated Load |
kg |
5000 |
5000 |
11 |
Lifting Height |
mm |
3000 |
3000 |
13 |
Free Lifting Height |
mm |
205 |
145 |
12 |
Load Center |
mm |
600 |
500 |
14 |
Fork Size |
Long×Wide×Thick |
mm |
1220x150x55 |
1070x150x50 |
15 |
Mast Dip Angle |
Front/Rear |
。 |
6/12 |
6/12 |
16 |
Minimum Turning Radius |
mm |
3250 |
2800 |
17 |
Minimum Stacking Right Angle Aisle Width |
mm |
5500 |
4740 |
18 |
Minimum Right Angle Aisle Width |
mm |
2960 |
2800 |
19 |
Minimum Ground Clearance |
mm |
200 |
160 |
20 |
Front Overhang |
mm |
610 |
560 |
|
Performance |
|
|
|
|
21 |
Max.Travelling Speed |
Full load |
km/h |
26 |
19 |
22 |
Max. Lifting Speed |
Full load/without loading |
mm/s |
500 |
400 |
23 |
Max. Traction |
Full load |
KW |
51.4 |
22 |
24 |
Max. Gradeability |
% |
20 |
18 |
25 |
Max. Fork Lifting height |
With Load Backrest |
mm |
4380 |
4260 |
|
Dimension |
|
|
26 |
Overall Length |
Without Fork |
mm |
3430 |
3060 |
27 |
Overall Width |
mm |
2235 |
1480 |
28 |
Overhead Guard Height |
mm |
2460 |
2350 |
29 |
Mast Landing Height |
mm |
2500 |
2240 |
|
Chassis |
|
|
|
|
30 |
Tire |
Front |
|
8.25-15-14PR |
300-15-18PR |
31 |
Rear |
|
8.25-15-14PR |
7.00-12-12PR |
32 |
Wheel Base |
mm |
2250 |
2000 |
33 |
Wheel Tread |
Front/Rear |
mm |
1470/1700 |
1180/1190 |
34 |
Fuel Tank Volume |
L |
120 |
100 |
|
Curb Weight |
|
|
|
|
35 |
|
No-load |
Kg |
7980 |
6700 |
